AudioValve Sunilda Röhren Phono Vorstufe

A view of the compact and absolute wireless electronic – riaa modul from SUNILDA. There is no hum, bee or any noise – only music. The design on a double side pc board is constructed in double mono technology, use best and selected components and guarantee high stable and highend vinyl re – productions.

Sunilda is a three stage phono-preamplifier, based on 6922 (ECC88) and 12AX7 (ECC83) frame grid tubes, suitable for two MM- and MC-cartridges at the same time. Independently for the two phono inputs, impedance and capacitive load can be set separately and ‚on-the -fly‘ while listening. Thus the user can easily configure the unit to match the features of the cartridge by selecting the optimal input resistance and capacitance for each input separately!

Switches in front are found for: MM/MC mode for each input; input 1 or 2; selectors are used to select different resistor and capacitive input loads.

In MM mode the gain will be 23 dB lower than MC and at a fixed input-impedance of 47 K.

In MC mode the preamp will have 20 dB higher gain and switchable input resistors and condensers. The RIAA de-emphasis is passive and split between the first and second stage. Dividing the RIAA network over two amplification stages lowers the insertion losses of the passive network dramatically. Furthermore, the design holds a total absence of feedback, thus increasing the overall dynamics.

Power supplies are solid state regulated. This is the best way to obtain a low noise and supply line with a very low impedance that will increase the performance in the lower frequency range. The power transformer is housed in a separate aluminum case.

Sunilda comes in an lasercut, 3mm thick steel, chassis in black or silver finish and has a case similar to the Eklipse lineamplifier.

Technical Specifications:

Gain: MM 41dB, MC 63dB ( 1Khz )

Input LOAD resistors: 47 R, 100 R, 220 R, 470 R, 1 K, 47 K

Input LOAD capacitors: 0 p, 100 p, 220 p, 470p, 1000p

Frequency Response: 20Hz to 65 KHz +/- 3 dB

Subsonic filter roll-off: 20 Hz

Max output amplitude: 14V pk

RIAA accuracy max.: +/- 0,18dB

Distortion: MM 0,24 %, MC 0,32% (1Khz – 2V out)

Noise: MM – 63dB, MC – 73dB

Circuit type: 3 stages single ended, buffered ouputs

RIAA network: passive

Tubes: 2 x 6922 (6N1P), 2 x 12ax7

mode functions: Stand – by and mute

Power supplies: high accuray solid state regulated

Power transformer: outside housed

Power requirements: 115/230 – 245 Ac – 50/60Hz

Power consumption: Watts: 40 VA

Dimensions in cm: 42 B x 32 D x 14 H

Weight: 20 kg

Weiterführende Informationen:

Röhren: 2x ECC83, 1x ECC88, 1x ECC82, 1x EL84, 1x EF86

Eingänge: 1 Phono

Ausgänge: 1 Cinch

Eingangsempfindlichkeit: Phono: 0,4 mV

Eingangsimpedanz: Phono: max. 47 kOhm

Bandbreite: RIAA 20 Hz – 20 kHz

Ausgangsimpedanz: –

Stromversorgung: 230 V AC

Leistungsaufnahme: 20 W

Abmessungen (BxHxT): 45,5 x 12,5 x 32 cm

Gewicht: ca. 11 kg
